M1

The robust mulcher for medium-power tractors.

The new M1 is a compact professional forestry mulcher designed for medium-power tractors and for users requiring a versatile, reliable and high-performance machine, even in demanding working conditions. Equipped with a rotor fitted with fixed forestry tools with double tungsten carbide inserts, the M1 can mulch shrubs, stumps and branches up to 25 cm in diameter while ensuring high cutting quality and extended tool life. Its single side transmission and reinforced yet compact frame make the machine lighter and easier to handle, ideal for work on hilly terrain, embankments, woodlands and neglected areas. The optimised rotor exposure also enables light tree felling, while the 5 rows of internal counter-blades ensure fine, uniform shredding. Ideal for maintenance of: woodlands, hillsides, embankments, pastures, undergrowth, rural roads, abandoned land and light forestry work. Available in 3 working widths: 175, 200, 225 cm

Mount

Rear

Tractor HP

110 HP

Max. wood

25 cm

Rotor

Ø 450 mm

Drive

Mono transmission

PTO

1000 rpm (540 rpm optional)

• 1000 rpm gearbox with freewheel
• Height-adjustable bolted skids
• Hydraulic hood with double cylinder
• Reinforced double frame
• Belt transmission with automatic belt tensioner
• Front and rear chain protection
• CAT 2 three-point hitch
• Interchangeable bolted rotor hubs
• 5 rows of counter-blades
• Optional: mechanical push-down bar
• Optional: hydraulic push-down bar (with or without teeth)
• Optional: rear material deflectors
• Optional: CUT LIMITER rotor
• Optional: PTO shaft
• Optional: 540 rpm gearbox
